China V-Type Paint Filter Paper for Spray Booths – Quality Suppliers & Factory Solutions for Paint Mist Filtration
Main Features
1. Whirlpool Airflow Guide Design
Unique design promotes efficient airflow, improving the overall filtration efficiency of the filter.
2. V-type Depth Bearing
V-shaped structure has high dust holding capacity while maintaining low pressure drop to ensure optimal performance.
3. Easy Installation
Designed for easy installation, allowing for quick setup and replacement in a variety of systems.
4. Recycling Capacity
Facilitates the recycling of paint particles and dust, helping to reduce waste and achieve environmental sustainability.
5. Reproducible & Environmentally Friendly
The filter paper is made of environmentally friendly materials, with high efficiency and high repeatability.
6. Long Service Life
The filter paper adopts durable design and has a long service life, which reduces the frequency of replacement and maintenance.
Application
1. Industrial Use
Suitable for use across a variety of industries, this filter captures paint particles and dust, helping to reduce air pollution and maintain a safe working environment.
2. Waste Gas Purification
The filter can be effectively used in exhaust gas purification systems, helping to minimize harmful emissions and improve air quality.
3. Customization Options
Filters are available in custom sizes and can be cut or framed to exact requirements. Can be used as stand-alone filters or integrated into complete filtration systems.
Specification
High Filtration Efficiency: Designed to effectively capture fine particles, ensuring cleaner air.
Low Pressure Drop: Maintains airflow while effectively filtering contaminants.
Environmental Compliance: Create a healthier working environment by reducing air emissions.
This V-shaped paint filter paper is an essential solution for industries requiring efficient filtration of paint and oil mist, ensuring compliance with environmental standards and promoting a safer workplace.
| Filter class | Paint particles dust particles | Stretch break | 50mm |
| Flame retardant grade | K1(DIN 53438) | Wet tolerance (relative humidity) | <80%RH |
| Aperture | 25mm | Hole distance | 20mm |
| Final resistance | 150Pa (recommended) | Temperature | <100°C maximum in continue service |
| Instantaneous temperature | <120°C | Material | Excellent double Kraft Fiber Paper |
| Size: 1000*80*6cm | 1000*90*6cm | 1000*100*6cm | |||
| Note: Special Size Available Upon Request. | |||
